2003 Chopper Coil Cover

[C00lHandLuke]

The other day I was looking at a few 2003 Choppers on the internet and I noticed something. My 2003 Chopper has a rounded, chrome coil cover with no logo or any other design on it. One of the 2003 Choppers I noticed had a completely different coil cover. The cover was flat and had the older BDM logo on it along with "107 Cubic Inches" I was just curious to the difference. Did I just see a 2003 Chopper that had been modified with a different BDM coil system, or did BDM just use two different coil covers on the 2003 chopper? If so, is it the same coil system with just a different cover? In other words, can either cover be used on the 2003 Chopper coil?

Mine

One that I saw on another 2003 Chopper

Thanks.



[Slick-Dog]

Luke..My 03 chopper has the flat one like in the pic...what the last 4#`son your vin# could of been made in a later date.....and no I still dont have the extensions put on yet LMAO!! After that trip I havent even looked at my K9...



[HMAN]

Luke, your's looks just like mine on the 04 Pit. Mine has a 10 year logo on it. That would be the only difference. I think the flat ones were the original 03's. Like Slick said, your's could be an end of the year bike and they just put on the newer style coil cover.....?



[C00lHandLuke]

My last 4 is 0535. Is it the same coil though? If I wanted to switch to the other coil cover as long as I had the above bracket it would work?



[Th3InfamousI]

My last 4 is 0535. Is it the same coil though? If I wanted to switch to the other coil cover as long as I had the above bracket it would work?

yea you just need the coil bracket and cover. That bracket looks fairly standard just need a Big Twin Coil Bracket. Make sure you get a Big Twin because it will include a spacer required for clearing the large fins on your 107".

You can check out www.vulcanworks.net they have a bunch of different options.



[C00lHandLuke]

Thanks dude.



[woodbutcher]

from the way it looks part #2 mounts, you would not have any way of tying the motor to the motor mount of the frame. am i wrong? unless there is another part that is not shown. finding it would be the key.



[Th3InfamousI]

from the way it looks part #2 mounts, you would not have any way of tying the motor to the motor mount of the frame. am i wrong? unless there is another part that is not shown. finding it would be the key.

Wood, I would think you would be to still use the cameltoe mount for the frame. Although now that you mention it it appears that mount doesn't really have a hole in the center for it.

I posted the link the vulcan works website their motor mount comes with that piece.



[stlmikie]

I think th Og photo is missing an L bracket. I just snapped a photo of mine with the old style cover. I hope this help Luke.



[Mr. Wright]

Luke, the coil cover you have is an upgrade. The older flat ones was causing a lot more vibrations. Those of us that have the old flat one, have more that likely lost the bolt out of the L-bracket, where it bolts to the frame, a time or two. I wish I had the newer one, I think it looks a lot better than the flat one



[BDMCHOPPERFREAK]

I have an 03 Chopper with the Rolling Thunder frame. There was a frame recall (top tube gusset installed) and BDM offered to install the upgrade 04 coil cover as part of the package. I requested the upgrade and to have my original cover returned.



[BBChopper]

Mine has holes in it?



[stlmikie]

Holey moley!

Mine has holes in it?



[Th3InfamousI]

Mine has holes in it?

Intersecting

Did you machine that yourself?



[C00lHandLuke]

Thanks everyone, this is exactly the info I was looking for.



[TimNY]

I like the newer style also.I think its an upgrade also.I was told the older coil
covers loosen up.
BB I like the hole - cool mod.
