TP Boxes

[BBChopper]

Pulled the TP (Terrible Product) Rocker Boxes off today and there is no visible blow by from the valve guides!!! New (used) S&S’s going back on!:2thumbs:



[Eric]

good deal bbc.. I thought you were gona wait till after BW,, couldnt stand it could ya........



[BBChopper]

good deal bbc.. I thought you were gona wait till after BW,, couldnt stand it could ya........

As long as there wasnt damage I figured I should get them changed out!!!:2thumbs:



[RADAMS445]

Your this far into it-zero the deck-dust the heads(.003-.005)-cam and ignition. Wa-la your done!!http://



[outdoorsman26]

whats an avarage cost to deck the heads??



[linx]

Cool deal. I wanna change mine out eventually.



[reloaderbmg]

I was going to do a cam this year on the 07 k9 but after the surgery last oct. i am having trouble just hanging on lately,:roll::roll:



[RRRUFF]

BB, Looks like a pretty good wear pattern from what I can see. Wipe off the top of the valves and take pictures of the tops where the rocker contacts the valve.



[MARV]

a few more bolts then send them out to J Sachs!



[RRRUFF]

John's working my heads now. He is pretty sharp with this stuff, I don't think you will find any better.



[hollywoodjohnny]

Whats a set of S&S's go for ??



[RADAMS445]

Whats a set of S&S's go for ??

Roughly 300.00 with shipping,then you have to decided if you want the S&S rollers or not.:up:



[RADAMS445]

Whats a set of S&S's go for ??

Roughly 300.00 with shipping,then you have to decided if you want the S&S rollers or not.:up:
http://S & S Die-Cast Rocker Cover:eBay Motors (item 140368334206 end time Jan-16-10 15:13:20 PST)



[Vegas]

I'd still pull the heads and check the guides. For blow by like Ray had, they needed to be super sloppy.



[N8KAM]

As long as there wasnt damage I figured I should get them changed out!!!:2thumbs:

BB.. from what i was told the problem was not necessarily the TP boxes... as can be seen by the fact some here have a LOT of miles on them... the problem was the alignment of the box when it is torqued down. they use the bolts to align them and some have excessive movement and can be tightened down with the rocker off center of the valve steam.. Just keep that in mind when you reinstall them.:2thumbs:



[RRRUFF]

BB if you will post some better pictures of the valve stems where the rocker roller contacts the valve stem, I can tell from my experience. Also how many miles do you have on your bike? I have about 12k on mine and I wasn't far from major trouble.



[BBChopper]

BB.. from what i was told the problem was not necessarily the TP boxes... as can be seen by the fact some here have a LOT of miles on them... the problem was the alignment of the box when it is torqued down. they use the bolts to align them and some have excessive movement and can be tightened down with the rocker off center of the valve steam.. Just keep that in mind when you reinstall them.:2thumbs:

Did a test fit last night. Seems if you start all the bolts then push the rocker box to the left and let it center on the bolt's snug it down then drop a rocker in it's dead center. But if you push to the right to center it's off.:up:



[MARV]

Did a test fit last night. Seems if you start all the bolts then push the rocker box to the left and let it center on the bolt's snug it down then drop a rocker in it's dead center. But if you push to the right to center it's off.:up:

you also move the lower box around for spring clearance.



[Raywood]

I may have to pull mine agian and ensure I had mine centered or placed right. I don't remember having any slop or movement in them now but guess it would be worth going back and checking.



[Vegas]

Are you sure they shouldn't be indexed with some dowels or sleeves?
