Long story. My 2005 Mastiff started to quit on me due to fuel starvation. After several "fixes", it was decided the tank liner was flaking off, clogging up the fuel line. The tanks were removed, re-lined, and re-painted. The mechanic is nowhere to be found. So, I have to try to get them back on! Anybody know of a good step by step source??
2005 MASTIFF GAS TANK INSTALLATION HELP!
- Thread starter Dano
- Start date
CCRainman
Well-Known Member
I am gonna try to link a couple of pics that might help you.
In the first pic the bracket towards the triple tree is where you mount the tanks with the rubber grommets
The second bracket is where the indicator goes but you need to put your console on.
Then comes the EHC whic is the black thin then the final screw on the bottom of the console. The last bracket is where your bottom of the tank comes together and there is a tube there. Hope this help you.
In the first pic the bracket towards the triple tree is where you mount the tanks with the rubber grommets
The second bracket is where the indicator goes but you need to put your console on.
Then comes the EHC whic is the black thin then the final screw on the bottom of the console. The last bracket is where your bottom of the tank comes together and there is a tube there. Hope this help you.
CCRainman
Well-Known Member
Can you get me a pic?
BadBrad
2005 Pitbull
The two top nipples have a rubber hose that connects them. Same thing on the bottom front of the tank. You should have a braided rubber hose that connects the two front bottom nipples. The top back nipple does not need a hose. It's for venting. I've never had anything on mine from that nipple. There should only be one and generally on the right half tank.
