Cam, Rocker Boxes, Roller Rocker Arms, and Lifters

[Dan22644]

Starting a big project since its raining like crazy in FL. Replacing the TP boxes with some S&S ones I got on Ebay. Replacing the lifters with some Crane Cams lifters. Replacing the stock rocker arms with TP roller rockers. And upgrading to the 585 cam! Wish me luck...



[Raywood]

FYI, your TP topend already has TP toller rockers



Sent from my DROID RAZR using Tapatalk 2



[Dan22644]

Yeah thats funny, everything I ever read on this site said I should NOT have the roller rockers??? I guess I will have rocker arms for sale...

Now for a question, I have all the bolts out of the TP box, but it is seriously stuck to the gasket. Whats the safe way to break it free???



[KaptinAmerika]

Gentle tapping with a rubber mallet and wood block wrapped in a soft cloth.
Just be patient and careful as when they pop loose be ready so they don't fall and hit something.



[Dan22644]

OK, will do.



[Th3InfamousI]

Good luck!

Clean shop! fuck mine is a god damn mess!



[Dan22644]

If you are going to remove the rocker boxes on a Bulldog, save yourself all kinds of time and effort and just remove the gas tank right away :bang:



[Dan22644]

Oh, and what valve springs are these???



[Dan22644]

Can't get the cam cover off, what do I do with this?



[Dan22644]

OK I finally got that cover off, it was really on there! Then I see this... Looks like this bike had the .569 comp cam put in....



[Raywood]

Yes, standard info on here. Early 05's and 6's had .569 compcams and later they went yo the .549's



Sent from my DROID RAZR using Tapatalk 2



[V]

Oh, and what valve springs are these???

As I was told that is a Comp spring. They told me it was a double spring with a flat wound inner (spring as I call it) for harmonics. What the actual rating is they would not say. it has been a debateas to the max lift you could run when these. In the 05 I had I installed the .600 cam but I upgraded to the S&S .640 springs.



[V]

Is it me or are the S&S rocker boxes in your picture missing a bolt hole right next to the compression release? As I remeber there were 2 allen head bolts in the flat of the rocker box? Might compare it to the TP's you have to make sure.

I bought a rocker box of ebay and it was not the same as what was on the bike.

Might double check and I could very well be totally wrong. Me memory is shot.



[Dan22644]

Is it me or are the S&S rocker boxes in your picture missing a bolt hole right next to the compression release? As I remeber there were 2 allen head bolts in the flat of the rocker box? Might compare it to the TP's you have to make sure.

I bought a rocker box of ebay and it was not the same as what was on the bike.

Might double check and I could very well be totally wrong. Me memory is shot.

You are correct sir, one less hole, the one very close to the compression release. I'm calling S&S tomorrow, I'll add this to my list of questions.


Sent from my HTC One X using Tapatalk 2



[Dan22644]

As I was told that is a Comp spring. They told me it was a double spring with a flat wound inner (spring as I call it) for harmonics. What the actual rating is they would not say. it has been a debateas to the max lift you could run when these. In the 05 I had I installed the .600 cam but I upgraded to the S&S .640 springs.

Has anyone run these springs with the 585 cam without issues???


Sent from my HTC One X using Tapatalk 2



[Dan22644]

As I was told that is a Comp spring. They told me it was a double spring with a flat wound inner (spring as I call it) for harmonics. What the actual rating is they would not say. it has been a debateas to the max lift you could run when these. In the 05 I had I installed the .600 cam but I upgraded to the S&S .640 springs.

Has anyone run these springs with the 585 cam without issues???

Sent from my HTC One X using Tapatalk 2



[Dan22644]

Ok, unless someone can tell me what these springs are good for, this project is a complete failure. The valve covers will not fit as they are for an Evo motor head and the 117 uses a TC head, I already had the roller rockers, and I don't know if I can use this cam.

I'm sure all this knowledge was already on the forum, but I didn't see it

I think I'm just going to put it all back together and sell the parts. Look for a good deal in the swap meet!!

Sent from my HTC One X using Tapatalk 2



[dnespolo]

I'm not 100% sure but I believe the spring are good at least up for 585 cams.



[Dan22644]

I'm not 100% sure but I believe the spring are good at least up for 585 cams.

No offense, but do you have a source for your hunch? I talked to a guy at CompCams today and he said there are two possible kits that were sold to Big Dog with the 30-4000 cam, both had double springs with the flat damper, but no way of knowing which ones I had without measuring the seat pressure. Of course one of them can handle a cam with over 585 lift, and one cannot

Sent from my HTC One X using Tapatalk 2



[Zachusmc]

I build 700+ Hp racing engines every day I just want to say this valve springs take a lot of abuse and over time weaken so why not do your self a favor and just get new valve springs that way you know they are good and it is cheap insurance to protect your engien from serious failure just my opinion but I see it ever day.
