1996 Big Dog Vintage parts list

knothead

Second Chance Customs
Supporting Member
1996 Big Dog Vintage parts list...most part are drag specialties or v-twin....parts very from 1967-1986...harley wide glide FXWG ,FLH and fxr...

1...GMA doesnt have these 10" front disc so v-twin does in a different style... part number 23-0311 or your choice

2...Front wheel 40 spoke dual disc....36-313....make sure to see if you have 5/16" rotor bolts or 7/16" rotor bolts....5/16" rotor bolt part is 36-313....7/16" rotor bolts is 36-305....thats the only difference in the wheels

3...KIckstand....27-0509....but its not exact had to modify cause orginal is discontinued...

4...gas caps and savers....200-000024...bdm parts or try another company....one left hand and one right hand

5...rear brake pedal....23-0677 and you will have to put a piece of 1/8" to 1/4" rubber under it to get the right spacing plus helps the chrome from not getting damaged..

6...GMA rear brake master cylinder there are different finishs but chrome is....233004

7...rear master cylinder plunger...23-0116
8...driver floorboards... 50-34044A-05
9...rear brake caliper anchor arm...26483 or 57618
10...rear axle adjuster slide plates...44-1989
11...top belt guard....DS-325176
12...v-twin swingarm isolators....31-0442 has a flat spot in the 9/16" hole which is a easy fix with a die grinder just dont take out to much

13...front isolator mount....DS-243515
14...70 tooth pulley cover...91733-85
15...ISO antivibe heal shift peg....44152
16...ISO antivibe toe peg....21-1665
17...rear fender chrome trim with red lens....07-81281

18...mustang solo seat....75558
19....big dog saddle bags....good luck finding those lol...

20....20" lowboy sissy bar back....50-0462
21....sissy bar side plates....50-0805
22....pad and chrome plate....BD432-89
23....v twin luggage rack 50-1011
24....drag specialties 0610-0505 front brake master cylinder complete kit 84-86 harley wide glide.....fits alot of different models also

25.... superior dixie 6 terminal ignition switch 71501-73

26.... fork seals 80-83 fxwg or 77-84 fhl will work...but part# for 80-83 fxwg, which is what is, is 45843-77....also use 20 weight fork oil....9.0 to 10.2 ounces....i use 11.5 ounces for firmer ride....also find a 41mm dust cap seal to cover up the oil seals....

27..... gma rear brakes is a "A" pads...
28..... gma front brakes pads is "F" for the dual pistons

29....spotlight and blinker bracket clamp...superior 68795-68

More parts list to come....stay tuned


Reply
Report •••

Last edited:

Th3InfamousI

Administrator
Staff member
1996 Big Dog Vintage parts list...most part are drag specialties or v-twin....parts very from 1967-1986...harley wide glide FXWG and FLH...

1...GMA doesnt have these 10" front disc so v-twin does in a different style... part number 23-0311 or your choice
2...Front wheel 40 spoke dual disc....36-313
3...KIckstand....27-0509....but its not exact had to modify cause orginal is discontinued...
4...gas caps and savers....200-000024...bdm parts or try another company....one left hand and one right hand
5...rear brake pedal....23-0677 and you will have to put a piece of 1/8" to 1/4" rubber under it to get the right spacing plus helps the chrome from not getting damaged..
6...GMA rear brake master cylinder there are different finishs but chrome is....233004
7...rear master cylinder plunger...23-0116
8...driver floorboards... 50-34044A-05
9...rear brake caliper anchor arm...26483 or 57618
10...rear axle adjuster slide plates...44-1989
11...top belt guard....DS-325176
12...v-twin swingarm isolators....31-0442 has a flat spot in the 9/16" hole which is a easy fix with a die grinder just dont take out to much
13...front isolator mount....DS-243515
14...70 tooth pulley cover...91733-85
15...ISO antivibe heal shift peg....44152
16...ISO antivibe toe peg....21-1665
17...rear fender chrome trim with red lens....07-81281
18...mustang solo seat....75558
19....big dog saddle bags....good luck finding those lol...

More parts list to come....stay tuned

Last edited: Yesterday at 6:56 PM
Reply
Report •••
great thread! Stickey material, just keep adding to your post so it stays together!
