T-Bag Install

Discussion in 'How-To' started by Mickeetwo, Oct 2, 2008.

Thread Status:
Not open for further replies.
  1. Mickeetwo

    Mickeetwo Guru
    Supporting Member

    Joined:
    Nov 28, 2007
    Messages:
    9,512
    Likes Received:
    823
    Trophy Points:
    113
    Location:
    Texarkana, AR
    My Bike(s):
    2006 Big Dog K9 & 2014 Ultra Limited
    First Name:
    Alan
    I have the BDM Touring T-Bag with the Roll Bag. I've always had a problem keeping the bag off the rear fender. Whenever you load the bag full with a lot of weight it starts to sag and the the bag rest on the fender. The way the luggage rack is designed it doesn't keep the bag off the fender. When I went on my trip last week I knew I would be loading my bags full. So I came up with this idea. Thought it might help.

    Went to a glass shop and purchased a 9"x14" piece of lexan. It is 1/4" thick. Trimmed it down to the size of the T-bag. Marked and cut out holes for my velcro to loop threw. The velcro first wraps around the luggage rack and then through the lexan and then back around. The soft velcro keeps the lexan from marring up the chrome luggage rack. When the T-bag is installed you cannot see the lexan. Takes less than a minute to remove the lexan. The lexan keeps the T-bag clear of the rear fender no matter how much you put in it. just thought it might help save a paint job :D

    [​IMG]

    [​IMG]

    [​IMG]

    Road over 900 miles and the lexan never moved. Another plus to the lexan is that when it rains it will help block some of the rain water that comes off the rear tire.....keeping your stuff a little dryer.

    KnotSo likes this.
  2. Raywood

    Raywood The Pirate
    Staff Member Supporting Member Calendar Participant

    Joined:
    Apr 5, 2007
    Messages:
    17,356
    Likes Received:
    626
    Trophy Points:
    113
    Location:
    Rainbow, CA
    My Bike(s):
    2014 KMW Regulator
    First Name:
    Ray
    Great post Mick, my problem with the bag shelf is that it's not 90 degrees to the sissybar causing it to deform. Gonna have one of those custom bars made as others have here with a proper fitting shelf.

    I've been thinking of doing the same as you did here.
    Thanks,
    Ray

  3. seatmaker

    seatmaker Well-Known Member

    Joined:
    Apr 9, 2007
    Messages:
    2,155
    Likes Received:
    98
    Trophy Points:
    48
    Location:
    Spitten distance from Hell,Michigan
    My Bike(s):
    2012 Ultra Classic
    Been there done that, mine needs rubbed out because of the same thing. Think I'm gonna design a leather hammock of some sort which would look good when nothings on it yet keep the fender free of the bag when it is.

  4. dingo

    dingo Proud to be a

    Joined:
    Jul 15, 2007
    Messages:
    2,282
    Likes Received:
    81
    Trophy Points:
    48
    Location:
    Long Island, NY
    My Bike(s):
    06 K9
    First Name:
    Chris
    Great Post Mick :2thumbs: :2thumbs: ......I know what I'm doing this weekend.

  5. Gas Man

    Gas Man Cool isn't cheap
    Supporting Member Calendar Participant

    Joined:
    Apr 8, 2007
    Messages:
    15,048
    Likes Received:
    252
    Trophy Points:
    83
    Location:
    Metro Detoilet
    Great idea!!!!!

  6. Slow Vince

    Slow Vince Active Member

    Joined:
    Oct 16, 2007
    Messages:
    297
    Likes Received:
    5
    Trophy Points:
    18
    Location:
    Wasilla, Alaska
    My Bike(s):
    2007 K9, 2002 HD Nitetrain
    Sure wish that I'd thought of it BEFORE I got some chafing on the fender...

    Was so kicking myself in the butt that I did the same thing with a piece of plywood and tie-wraps. The Lexan sure would look better - Winter Project.
    ;^}

  7. Tim

    Tim a.k.a. BubbleHead
    Staff Member Owner/Founder Troop Supporter Calendar Participant

    Joined:
    Feb 22, 2007
    Messages:
    11,715
    Likes Received:
    963
    Trophy Points:
    113
    Location:
    Austin, TX
    My Bike(s):
    '07 K-9
    First Name:
    Tim
    Great idea, thanks for sharing with us all. :cheers:

  8. scubaman15

    scubaman15 Well-Known Member

    Joined:
    Dec 9, 2007
    Messages:
    2,861
    Likes Received:
    60
    Trophy Points:
    48
    Location:
    New Kent Virginia
    My Bike(s):
    2007 BDM Chopper- 2007 HD CVO
    Good idea ...

  9. RRRUFF

    RRRUFF Well-Known Member
    Supporting Member

    Joined:
    Jun 20, 2007
    Messages:
    3,022
    Likes Received:
    100
    Trophy Points:
    63
    Location:
    Georgia
    My Bike(s):
    2005 Big Dog Chopper
    I was thinking of putting something like lexan or plywood in the bottom of the bag.:job:

  10. Whistler

    Whistler Active Member

    Joined:
    Feb 4, 2008
    Messages:
    267
    Likes Received:
    5
    Trophy Points:
    0
    Location:
    East Texas
    My Bike(s):
    2008 Big Dog K-9 EFI, 2012 Electra Glide Ultra Limited
    Good idea Mick. Another option to experiment with would be to cut a piece of plastic in a rectangular shape to snuggly fit in the bottom of the bag then pile your stuff in on top of it so that the bag has a firm bottom and shouldn't sag. This way nothing shows outside the bag. Just a thought - I'll try it and see how it works.

    :2thumbs: :2thumbs: :2thumbs:

  11. PROFLYER

    PROFLYER SWOLE
    Supporting Member

    Joined:
    Oct 8, 2007
    Messages:
    1,899
    Likes Received:
    921
    Trophy Points:
    113
    Location:
    Denver, CO
    My Bike(s):
    06 K9, 06 Mastiff (wife's)
    First Name:
    Sutton
    damn good idea...wanna make me one? :D :D :D

  12. Mickeetwo

    Mickeetwo Guru
    Supporting Member

    Joined:
    Nov 28, 2007
    Messages:
    9,512
    Likes Received:
    823
    Trophy Points:
    113
    Location:
    Texarkana, AR
    My Bike(s):
    2006 Big Dog K9 & 2014 Ultra Limited
    First Name:
    Alan
    Pro...I know you can pull this one off. Took less than 30 minutes to complete. Cost is $10.00 for lexan and $2.99 for velcro. Thought about installing it inside the bag, with the BDM T-bag there is a zipper on the bottom that is real close to the fender no matter what you do. Was worried about the lexan ripping a hole in the T-bag after a while. Went on a ride a few week ago and got caught in a downpour. Slipped the waterproof bag over my T-bag and took off. After the rain stopped removed the waterproof cover and noticed everything in the bottom of the T-bag was wet. When you install the waterproof bag over the T-bag theres still a small area that water can get in. With the lexan on the outside of the bag, it should help block the water. Also used my ROK straps that I purchased with the group buy, and they really work. I highly recommend the ROK straps. Made strapping things down a lot easier. Used D-rings on the T-bag and ROK straps off the D-rings.

  13. Raywood

    Raywood The Pirate
    Staff Member Supporting Member Calendar Participant

    Joined:
    Apr 5, 2007
    Messages:
    17,356
    Likes Received:
    626
    Trophy Points:
    113
    Location:
    Rainbow, CA
    My Bike(s):
    2014 KMW Regulator
    First Name:
    Ray
    Mick, the cover is not designed to be used while rolling down the road. I figured this out after reading the instructions after mine shreaded while riding in the rain at Little Sturgis a few years ago!!!

    :2thumbs: :cheers: :2thumbs:



  14. Mickeetwo

    Mickeetwo Guru
    Supporting Member

    Joined:
    Nov 28, 2007
    Messages:
    9,512
    Likes Received:
    823
    Trophy Points:
    113
    Location:
    Texarkana, AR
    My Bike(s):
    2006 Big Dog K9 & 2014 Ultra Limited
    First Name:
    Alan
    I never new that. At least mine didn't shread to pieces. Who would have thought to read the instructions :D

  15. RenoMoe

    RenoMoe Guest

    Great Idea!! I used a piece of wood, but the lexan is a much better looking option - Great Job!!

  16. wuudogg

    wuudogg Member

    Joined:
    Mar 28, 2008
    Messages:
    116
    Likes Received:
    0
    Trophy Points:
    0
    My Bike(s):
    '06 Pitbull
    If you need a quick fix while on the road for your "Saggy Bags"... just grab a friendly realtor or advertiser sign. You often find them littering the roads. They are usually made of Coroplast Plastic. Basically corrugated plastic. In between cardboard and lexan but it can handle getting wet.

    Cut it with a pair of scissors or a knife you can get something to fit and stuff inside your bag to help it hold shape.

    [​IMG]
