Stash Bag Bracket Cracks: How to make a new one

Discussion in 'How-To' started by chacha, Jun 27, 2007.

Thread Status:
Not open for further replies.
  1. chacha

    chacha Chaff Your EHC!!
    Calendar Participant

    Joined:
    Apr 18, 2007
    Messages:
    2,642
    Likes Received:
    111
    Trophy Points:
    63
    Location:
    20151
    My Bike(s):
    2001 Nightrain, 2014 Indian Vintage, 2006 Bulldog (sold)
    First Name:
    Mister Fucking Wonderful
    OK, so I'm noticing my left stash bag is feeling loose. So I feel up in there (it's as tight as a twelve-year-old between the bag and the frame), and sure enough, there's a nice old crack along the second bend.

    Here's a couple shots of the crack. There was rust in the cracks, so it had been there for a while.

    [​IMG]
    [​IMG]

    Pretty flimsy build, so I break out the 16 GA steel and start to work.

    First I made a template of the bracket and transfered it over to the steel.
    [​IMG]
    [​IMG]

    Then jig out the template and mark your holes.

    [​IMG]

    Then put some temp bends in and rough fit it to the frame. Your basically putting a big flat washer between the strut and the frame, so you want it to be as flat as you can get before clamping it down.

    [​IMG]

    Slap on some paint (I like flat black Rustoleum for these kind of things)

    [​IMG]

    And mount her up;

    [​IMG]

    I garrentee there ain't gonna be no cracks in that bracket no matter how much she shakes! If you got one of these, it may be worth taking a look at your bracket. I had around 6,000 miles on that bracket before I noticed the problem...

  2. Gas Man

    Gas Man Cool isn't cheap
    Supporting Member Calendar Participant

    Joined:
    Apr 8, 2007
    Messages:
    15,043
    Likes Received:
    274
    Trophy Points:
    83
    Location:
    Metro Detoilet
    Good work Chacha... that is awesome man!!

  3. Tim

    Tim a.k.a. BubbleHead
    Staff Member Owner/Founder Troop Supporter Calendar Participant

    Joined:
    Feb 22, 2007
    Messages:
    11,740
    Likes Received:
    1,008
    Trophy Points:
    113
    Location:
    Austin, TX
    My Bike(s):
    '07 K-9
    First Name:
    Tim
    Great job, love seeing guys build their own parts. :cheers:

  4. chacha

    chacha Chaff Your EHC!!
    Calendar Participant

    Joined:
    Apr 18, 2007
    Messages:
    2,642
    Likes Received:
    111
    Trophy Points:
    63
    Location:
    20151
    My Bike(s):
    2001 Nightrain, 2014 Indian Vintage, 2006 Bulldog (sold)
    First Name:
    Mister Fucking Wonderful
    Thanks guys. I like a good challenge ... I'm working now on building a drain plug to mount to the frame like on a HD softail. The 2004 models just have a drain hose hanging off the tank.

    Gas Man is the reason I take pictures of everything :D
    I figure if it happens to me, then it may happen to someone else....

  5. alhall88

    alhall88 UAW

    Joined:
    Apr 9, 2007
    Messages:
    2,121
    Likes Received:
    63
    Trophy Points:
    48
    Location:
    Petersburg, Michigan
  6. Tim

    Tim a.k.a. BubbleHead
    Staff Member Owner/Founder Troop Supporter Calendar Participant

    Joined:
    Feb 22, 2007
    Messages:
    11,740
    Likes Received:
    1,008
    Trophy Points:
    113
    Location:
    Austin, TX
    My Bike(s):
    '07 K-9
    First Name:
    Tim

    That looks pretty easy to make it you have some simple tools at home, like a tap and die set and maybe a belt sander. I bet you could make one of those for less then $20 and then paint it the same color as the frame.

  7. BIKERDAD61

    BIKERDAD61 Puddle Pusher

    Joined:
    Apr 12, 2007
    Messages:
    928
    Likes Received:
    5
    Trophy Points:
    0
    Location:
    Indiana
    My Bike(s):
    2007 H-D Ultra Classic
    looks like you could make one from a 3/8" steel pipe coupling, 3/8" pipe plug, 3/8" pipe to hose barb fitting and a small piece of bar stock. All this should be available at Lows or any hardware store.:up:

  8. chacha

    chacha Chaff Your EHC!!
    Calendar Participant

    Joined:
    Apr 18, 2007
    Messages:
    2,642
    Likes Received:
    111
    Trophy Points:
    63
    Location:
    20151
    My Bike(s):
    2001 Nightrain, 2014 Indian Vintage, 2006 Bulldog (sold)
    First Name:
    Mister Fucking Wonderful
    Yep, thats the idea. Drag make something similar to the ebay deal. I'm thinking if plumbing somthing up and welding it to the frame behind the shocks someplace....just an idea right now :loony:

  9. Tim

    Tim a.k.a. BubbleHead
    Staff Member Owner/Founder Troop Supporter Calendar Participant

    Joined:
    Feb 22, 2007
    Messages:
    11,740
    Likes Received:
    1,008
    Trophy Points:
    113
    Location:
    Austin, TX
    My Bike(s):
    '07 K-9
    First Name:
    Tim
    But you have an idea of what needs to be done.
