How to adjust your clutch (05 and newer)

Discussion in 'How-To' started by tacoloco, Jan 2, 2008.

Thread Status:
Not open for further replies.
  1. tacoloco

    tacoloco Member

    Joined:
    Dec 13, 2007
    Messages:
    36
    Likes Received:
    10
    Trophy Points:
    0
    Location:
    Tampa, FL
    My Bike(s):
    2008 Big Dog Ridgeback
    My shifting was hard and finding neutral was difficult. After adjusting my clutch, my shifting is now smooth and finding neutral is a breeze. This is how I did it. After leveling the bike, slide the clutch cable boot to access the cable adjuster
    [​IMG]
    Loosen lock nut and turn adjuster clockwise to loosen cable and give full slack to your clutch lever. It should look like this.
    [​IMG]
    Now remove the clutch adjusting cover to access the adjusting hardware.
    [​IMG]
    Loosen jam nut with 11/16 wrench and turn pushrod clockwise with a 7/32 Allen wrench until stops (only with light force) now turn pushrod counterclockwise ¼ of a turn and tighten jam nut.Install cover.
    [​IMG]
    Finally adjust your cable to give your clutch lever 1/16 of free play. Tighten the jam nut and slide the boot back in place.
    Enjoy your smooth clutch. If this adjustment doesn’t do the trick for you, consult your near BD dealer.:)

  2. Gas Man

    Gas Man Cool isn't cheap
    Supporting Member Calendar Participant

    Joined:
    Apr 8, 2007
    Messages:
    15,048
    Likes Received:
    252
    Trophy Points:
    83
    Location:
    Metro Detoilet
    Good work

  3. Chopper Dave

    Chopper Dave SIICK!!!

    Joined:
    Apr 13, 2007
    Messages:
    8,445
    Likes Received:
    82
    Trophy Points:
    48
    Location:
    Michigan
    My Bike(s):
    2011 Ultra Limited
    First Name:
    Dave
    good post!:up:

  4. f-okie

    f-okie AllGaveSome-SomeGaveAll

    Joined:
    Nov 14, 2007
    Messages:
    551
    Likes Received:
    13
    Trophy Points:
    18
    Location:
    Sand Springs, Ok
    My Bike(s):
    06 Bad Ass K9
    First Name:
    Richard
    Very straight forward:2thumbs:

  5. lee

    lee Well-Known Member

    Joined:
    Nov 5, 2007
    Messages:
    4,817
    Likes Received:
    65
    Trophy Points:
    48
    Location:
    Bristol, England
    My Bike(s):
    2005 Big Dog custom build and Buell custom build
    good shit that - I need to have a look at mine so very useful

  6. BBChopper

    BBChopper Supports 2 Disabled Vets
    Troop Supporter

    Joined:
    Nov 1, 2007
    Messages:
    17,484
    Likes Received:
    1,327
    Trophy Points:
    113
    Location:
    Fellsmere Fl,
    My Bike(s):
    2005 BDM Choppa "Wild Fire", 2011 Electra Glide Ultra Limited "Swamp Rat"
    First Name:
    Pablo
    Great post tac!!!!:2thumbs:
    Hey Lee place a pin on the map so we can see just where ya are over there!:eek:

  7. seatmaker

    seatmaker Well-Known Member

    Joined:
    Apr 9, 2007
    Messages:
    2,155
    Likes Received:
    98
    Trophy Points:
    48
    Location:
    Spitten distance from Hell,Michigan
    My Bike(s):
    2012 Ultra Classic
    Thanks, saved to my favorites !!! That's worth a rep:up:

    #7 seatmaker, Jan 5, 2008
    Last edited: Jan 5, 2008
  8. Alicat

    Alicat Hanging out

    Joined:
    May 12, 2007
    Messages:
    975
    Likes Received:
    12
    Trophy Points:
    0
    Location:
    Close to Insanity, Michigan
    My Bike(s):
    o6 K-9
    Great post! I've been having all kind of problems with my clutch cable since they replaced it....

  9. lee

    lee Well-Known Member

    Joined:
    Nov 5, 2007
    Messages:
    4,817
    Likes Received:
    65
    Trophy Points:
    48
    Location:
    Bristol, England
    My Bike(s):
    2005 Big Dog custom build and Buell custom build

    how do I do that?

  10. lee

    lee Well-Known Member

    Joined:
    Nov 5, 2007
    Messages:
    4,817
    Likes Received:
    65
    Trophy Points:
    48
    Location:
    Bristol, England
    My Bike(s):
    2005 Big Dog custom build and Buell custom build
    tacoloco - did you have to take your exhaust off to do the adjustment?

  11. lee

    lee Well-Known Member

    Joined:
    Nov 5, 2007
    Messages:
    4,817
    Likes Received:
    65
    Trophy Points:
    48
    Location:
    Bristol, England
    My Bike(s):
    2005 Big Dog custom build and Buell custom build
    ok - I've done it

  12. seatmaker

    seatmaker Well-Known Member

    Joined:
    Apr 9, 2007
    Messages:
    2,155
    Likes Received:
    98
    Trophy Points:
    48
    Location:
    Spitten distance from Hell,Michigan
    My Bike(s):
    2012 Ultra Classic
    Did it work? :zdrool:

  13. tacoloco

    tacoloco Member

    Joined:
    Dec 13, 2007
    Messages:
    36
    Likes Received:
    10
    Trophy Points:
    0
    Location:
    Tampa, FL
    My Bike(s):
    2008 Big Dog Ridgeback
    Lee, I took my exhaust off to see if I could do any mods to it. You don't have to remove your exhaust to do the clutch adjustment. If your allen wrench does not fit, cut it in half to work around the exhaust.

  14. slowrower

    slowrower 2007 Mastiff

    Joined:
    Sep 24, 2007
    Messages:
    981
    Likes Received:
    13
    Trophy Points:
    0
    Location:
    Longwood, Florida
    My Bike(s):
    BDM 2007 Mastiff
    Thanks ... Good info to have when it comes time to make the adjustments. :2thumbs: :2thumbs:

  15. TCALZ06

    TCALZ06 Well-Known Member

    Joined:
    Nov 4, 2007
    Messages:
    1,139
    Likes Received:
    11
    Trophy Points:
    38
    Location:
    Chandler, AZ
    My Bike(s):
    07 Big Dog K9
    First Name:
    Tom
    Great write up I just used it after dealer F'd up my clutch adj on my 5k service


    you might want to mention that the clutch adjusting cover spins off and I had to use a oil filter wrench with a adj rubber band to get it off.

  16. Raywood

    Raywood The Pirate
    Staff Member Supporting Member Calendar Participant

    Joined:
    Apr 5, 2007
    Messages:
    17,356
    Likes Received:
    626
    Trophy Points:
    113
    Location:
    Rainbow, CA
    My Bike(s):
    2014 KMW Regulator
    First Name:
    Ray
    Yeah, that SOB gets tight!!! I won't mention that I couldn't get mine loose but the mechanic at the dealer turned it right off........... Won't tell you SHE was a small little girl!!! :eek:

  17. gooddoggie

    gooddoggie Member

    Joined:
    Apr 8, 2007
    Messages:
    114
    Likes Received:
    3
    Trophy Points:
    18
    Location:
    Downers Grove Il.
    Also another method to remove the clutch adjusting rod cover is to pick up one of those rubber tipped door stops at the hardware and saw or grind off the screw end flush that screws into the base board, then just place the rubber stopper end in one of the recess areas of the cover and tap lightly with a small hammer in a counter clockwise direction and it should come off easily, the rubber protects the chrome and won't do any damage. Don't forget antisieze when you reinstall it.

  18. ROCKETDOG

    ROCKETDOG Active Member

    Joined:
    Feb 22, 2008
    Messages:
    223
    Likes Received:
    9
    Trophy Points:
    18
    Location:
    Southwest Florida
    My Bike(s):
    '06 Chopper '08 K9 2010 Road King
    First Name:
    Rick
    Interesting thread...seeing that I just looked at it today about 30 minutes after my clutch cable broke! Clutch pull was gettin stiff then snapped and my lever was sittin on my grip. It's an '06 Chopper still under warranty - Any How-to threads with pics on handling this? Thx.

  19. outlawcrewcab

    outlawcrewcab Member

    Joined:
    Apr 21, 2008
    Messages:
    137
    Likes Received:
    0
    Trophy Points:
    0
    Location:
    Ft Worth TX
    My Bike(s):
    02 pitbull
    will this work on my 02 with a 5 speed? guess i need to go look

  20. outlawcrewcab

    outlawcrewcab Member

    Joined:
    Apr 21, 2008
    Messages:
    137
    Likes Received:
    0
    Trophy Points:
    0
    Location:
    Ft Worth TX
    My Bike(s):
    02 pitbull
    yep my 5 speed set up is not the same anyone know how to do it? i have the same problem with the bike hard to put in neutrul and its always feels like clutch is draging at redlight always moving forward
