Downshifting Issue

Discussion in 'Transmission / Drive' started by 429CV23, Jul 6, 2016.

  1. 429CV23

    429CV23 Member

    Joined:
    Oct 5, 2015
    Messages:
    108
    Likes Received:
    165
    Trophy Points:
    43
    Location:
    Colorado Springs
    My Bike(s):
    2000 Big Dog Bulldog
    First Name:
    Jeff
    Today the Dog started giving me problems downshifting. At times I'll have to push the shifter 4-5 times before it will drop into the next lower gear, a few times it shifted from 5th to neutral or 4th to neutral.
    I changed the trans oil within the last 1200mi using Royal Purple; checked the level and she's still full and purple.
    There are no issues with upshifting.
    Is this a failing shift fork?

    2000 Bulldog; 107" S&S; assuming an original Andrew's geared 5spd.

    chubs likes this.
  2. Mr. Wright

    Mr. Wright Guru
    Supporting Member

    Joined:
    Aug 27, 2012
    Messages:
    8,094
    Likes Received:
    11,683
    Trophy Points:
    113
    Location:
    Salem, Missouri
    My Bike(s):
    04 BD Chopper- 2002 1100 v-star
    First Name:
    Shannon
    Check this nut and see if it is loose, it is the adjustment nut for your shift forks. Don't screw around with it, just check and see if it is loose. Then check the eyelets on the shift rod, and make sure that their not froze up. Then we can go from there.
    [​IMG]

    chubs and cdogg556 like this.
  3. cdogg556

    cdogg556 Guru

    Joined:
    May 21, 2011
    Messages:
    7,066
    Likes Received:
    15,315
    Trophy Points:
    113
    Location:
    Folsom, Ca.
    My Bike(s):
    2009 Big Dog Mastiff, Chrome Package, DOC's ESC, 585 cam, VH Big Radius Exhaust, 2.5" fwd Controls
    First Name:
    John
    See the allen bolt at the bottom of the shift lever, that was loose on my bike, I was having a hard time getting into neutral, tightened it up and it works great!:old2:

    HMAN, chubs, Mr. Wright and 2 others like this.
  4. Bdm4ever

    Bdm4ever Well-Known Member
    Troop Supporter

    Joined:
    Sep 2, 2009
    Messages:
    1,642
    Likes Received:
    4,457
    Trophy Points:
    113
    Location:
    USA
    My Bike(s):
    Something Like K9
    First Name:
    Tony
    Good tip John. Think I'll check mine as well..


    chubs likes this.
  5. cdogg556

    cdogg556 Guru

    Joined:
    May 21, 2011
    Messages:
    7,066
    Likes Received:
    15,315
    Trophy Points:
    113
    Location:
    Folsom, Ca.
    My Bike(s):
    2009 Big Dog Mastiff, Chrome Package, DOC's ESC, 585 cam, VH Big Radius Exhaust, 2.5" fwd Controls
    First Name:
    John
    :agree: dat's fur sur Paul! :yesnod::old2:Whenever I find something loose or broken usually it's when I am cleaning the bike !:old2::cheers:

    BWG56 and chubs like this.
  6. Mr. Wright

    Mr. Wright Guru
    Supporting Member

    Joined:
    Aug 27, 2012
    Messages:
    8,094
    Likes Received:
    11,683
    Trophy Points:
    113
    Location:
    Salem, Missouri
    My Bike(s):
    04 BD Chopper- 2002 1100 v-star
    First Name:
    Shannon
    How about an update Jeff

    chubs and BWG56 like this.
  7. 429CV23

    429CV23 Member

    Joined:
    Oct 5, 2015
    Messages:
    108
    Likes Received:
    165
    Trophy Points:
    43
    Location:
    Colorado Springs
    My Bike(s):
    2000 Big Dog Bulldog
    First Name:
    Jeff
    Thanks for the info guys!
    Here's an update; didn't have time to get to her last night, the wife wanted to remove the stakes and wires on three of the big ponderosas we had moved a few years ago from the back of the property to the front. Sorry, first wife took priority. ;)

    I started tonight by adjusting the clutch; loosening the cable, removing the freeplay from the pushrod, backed it off 1/2 turn, adjusted the cable so I have about 1/16" play in the cable at the lever. When I started, there didn't seem to be any freeplay in the cable, just some freeplay in the lever itself.

    Moved on to the shift pawl. The locking nut was loose. I never could get equal spring tension for both upshift and downshift directions, but set it so there was equal travel. There is spring tension against upshifting, but really none against downshifting. This operation was performed while she was in 3rd gear.

    Haven't ridden her to test yet, but firing her up and testing movement between 1st, 2nd, and N in the garage the shifting seems tighter, more precise.

    I'll update again once I get her out for a ride.

    Mr. Wright, chubs and cdogg556 like this.
  8. 429CV23

    429CV23 Member

    Joined:
    Oct 5, 2015
    Messages:
    108
    Likes Received:
    165
    Trophy Points:
    43
    Location:
    Colorado Springs
    My Bike(s):
    2000 Big Dog Bulldog
    First Name:
    Jeff
    Took her for a short ride tonight. No change in downshifting, although when it does downshift, and upshifts, are tighter/more positive. 5th to 4th is fine, beyond that it takes 3-5 times before it downshifts. Hope it isn't the shifter pawl spring, I've read that is a real PIA to replace.

    chubs likes this.
  9. Mr. Wright

    Mr. Wright Guru
    Supporting Member

    Joined:
    Aug 27, 2012
    Messages:
    8,094
    Likes Received:
    11,683
    Trophy Points:
    113
    Location:
    Salem, Missouri
    My Bike(s):
    04 BD Chopper- 2002 1100 v-star
    First Name:
    Shannon
    Actually there not to bad. If you have any mechanical ability, you can handle it.

    chubs likes this.
  10. 429CV23

    429CV23 Member

    Joined:
    Oct 5, 2015
    Messages:
    108
    Likes Received:
    165
    Trophy Points:
    43
    Location:
    Colorado Springs
    My Bike(s):
    2000 Big Dog Bulldog
    First Name:
    Jeff
    How do you inspect the spring? Can it be done by removing the trans top cover?

    chubs likes this.
  11. Olde Man

    Olde Man Active Member

    Joined:
    Jul 22, 2009
    Messages:
    200
    Likes Received:
    93
    Trophy Points:
    28
    Location:
    Fort Wayne, IN
    My Bike(s):
    2006 K-9
    First Name:
    John
    Lubricate the heim joints on the shift rod even if you think it is ok. Any resistance doesn't allow the return spring to do it's job. How do I know????

    chubs and cdogg556 like this.
  12. HMAN

    HMAN Just like to ride
    Supporting Member

    Joined:
    Mar 21, 2011
    Messages:
    3,948
    Likes Received:
    3,325
    Trophy Points:
    113
    Location:
    Ks
    First Name:
    Harry
    1/2 turn seem like quite a bit? Usually a 1/4 turn or so will put you really really close...?

    chubs likes this.
  13. 429CV23

    429CV23 Member

    Joined:
    Oct 5, 2015
    Messages:
    108
    Likes Received:
    165
    Trophy Points:
    43
    Location:
    Colorado Springs
    My Bike(s):
    2000 Big Dog Bulldog
    First Name:
    Jeff
    The early BD service manual spec'd 1/2 turn. I've not played with a BD clutch before, so I went with the recommended parameter.
    I figure get it to the factory setting as a baseline, I can play with it later if I don't like the engagement/disengagement point.

    #13 429CV23, Jul 9, 2016
    Last edited: Jul 9, 2016
    chubs likes this.
  14. 429CV23

    429CV23 Member

    Joined:
    Oct 5, 2015
    Messages:
    108
    Likes Received:
    165
    Trophy Points:
    43
    Location:
    Colorado Springs
    My Bike(s):
    2000 Big Dog Bulldog
    First Name:
    Jeff
    I lubed the Heims and the shifter assy.
    I don't think the spring is broken. In N, there is equal movement of the shift lever in both directions, and the shift lever springs back into position.
    While in 1st gear, if I push the shifter down to downshift, it springs right back up. But, when in 3rd gear, there is only spring tension in the upshift direction.
    The pawl adjuster doesn't seem to have much adjustment to it, but maybe it is still out?

    chubs likes this.
  15. 429CV23

    429CV23 Member

    Joined:
    Oct 5, 2015
    Messages:
    108
    Likes Received:
    165
    Trophy Points:
    43
    Location:
    Colorado Springs
    My Bike(s):
    2000 Big Dog Bulldog
    First Name:
    Jeff
    OK, I'm a dumbass. I readjusted the shift pawl spring correctly and she shifts perfectly now!
    From the service manual:
    3. Check shifter pawl adjustment.
    (a) Shift transmission into third gear.
    (b) Move shift lever and check for the spring pressure in both directions without shifting out
    of 3rd gear. You should feel the pawl contact the drum in both directions.
    (c) Locate the shifter pawl screw and lock nut on the left side of transmission case, next to
    the shifter lever. Loosen the lock nut and turn the hex-type screw either clockwise or counter
    clockwise, until the spring pressure is the same when moving shifter in each direction.
    Tighten the lock nut when spring pressure and travel is equal and re-check when tight


    Just FYI for future searchers:

    I was mis-adjusting it because there is NO spring tension when adjusted properly. There is no 'detent' or center position feel either. The shift lever just moves back and forth smoothly, contacting the drum in either direction.
    If the pawl is adjusted too far in one direction, spring tension is felt when moving the shift lever in one direction, and the shift lever will spring back to the 'detent' position; the shift lever will then move the opposite direction from the 'detent' position without any spring tension. Hope that makes sense.

    HMAN, Nukeranger and chubs like this.
  16. Mr. Wright

    Mr. Wright Guru
    Supporting Member

    Joined:
    Aug 27, 2012
    Messages:
    8,094
    Likes Received:
    11,683
    Trophy Points:
    113
    Location:
    Salem, Missouri
    My Bike(s):
    04 BD Chopper- 2002 1100 v-star
    First Name:
    Shannon
    It's the little things that get you. We've all been there.

    chubs likes this.
  17. 429CV23

    429CV23 Member

    Joined:
    Oct 5, 2015
    Messages:
    108
    Likes Received:
    165
    Trophy Points:
    43
    Location:
    Colorado Springs
    My Bike(s):
    2000 Big Dog Bulldog
    First Name:
    Jeff
    I'm just happy this ended up being a $0 repair! :D

    chubs likes this.
  18. Nukeranger

    Nukeranger Nukeranger
    Supporting Member

    Joined:
    Nov 18, 2007
    Messages:
    6,168
    Likes Received:
    2,247
    Trophy Points:
    113
    Location:
    Luling, Louisiana
    My Bike(s):
    2008 Ridgeback, 02 Bonneville America, 07 Daytona 675, 01 Custom Bonneville 1968 BSA Chopper/Bobber
    First Name:
    Huw
    :old2::old2::old2:Glad you figured out and solved your problem. Now, try remembering this when you get older!:)
