Completed 6" forward control extensions

Discussion in 'Metal Fab' started by Bowhunter, May 5, 2010.

  1. Dozer1

    Dozer1 Active Member

    Joined:
    Jul 11, 2009
    Messages:
    686
    Likes Received:
    4
    Trophy Points:
    18
    Location:
    St. Louis, Missouri
    My Bike(s):
    06 K9
    First Name:
    Greg
    Very, VERY nice work!!! Like Thedeadone, I'm well over 6' tall, too. Have the 2" extensions, but even they're not long enough. Often still feel kinda cramped. Definitely have me thinking about the possibilities

  2. scubaman15

    scubaman15 Well-Known Member

    Joined:
    Dec 9, 2007
    Messages:
    2,860
    Likes Received:
    61
    Trophy Points:
    48
    Location:
    New Kent Virginia
    My Bike(s):
    2007 BDM Chopper- 2007 HD CVO
    This is really the best of the forum in MHO a sharing of ideas and experience!!! even though I don't have a need for this ,Great job!!! Great write up with pictures and even a follow up!!:2thumbs:

  3. erldawg

    erldawg Guru

    Joined:
    Jan 26, 2008
    Messages:
    5,531
    Likes Received:
    75
    Trophy Points:
    48
    Location:
    Raleigh, NC
    My Bike(s):
    2008 K-9 EFI
    First Name:
    Earl
    Looks like you hit a home run for postman...excellent job..:2thumbs::2thumbs:

  4. barhopper

    barhopper Another round please

    Joined:
    Jan 26, 2008
    Messages:
    3,306
    Likes Received:
    24
    Trophy Points:
    38
    Location:
    So Cal
    My Bike(s):
    04 RSD Bulldog
    It always pays to have friends smarter than you. :cheers:

  5. B RADDD

    B RADDD Active Member

    Joined:
    Mar 29, 2010
    Messages:
    752
    Likes Received:
    4
    Trophy Points:
    18
    Location:
    PLANT CITY FL
    My Bike(s):
    07' k9, 10' street glide , XR 400
    First Name:
    B RADD
    I'm 6'2 with bd extentions ,they seem to work for me, I have friends in the 6'4to 6'6 range and the reason they dont have a dog is cuz they dont feel comfortable on my bike, if u market this we may see alot more taller riders :2thumbs::cheers:

  6. Bowhunter

    Bowhunter Well-Known Member

    Joined:
    Mar 5, 2010
    Messages:
    2,270
    Likes Received:
    347
    Trophy Points:
    83
    Location:
    Oliver Springs, Tn.
    My Bike(s):
    2009 K9
    First Name:
    Steve
    I have what looks like good news! KaptanAmerika is wanting to be the go to guy for the kits. I am going to work with him on the templates and he is going to try and put this together for you fellow long-legged bikers. I am going to extend mine to about 4" after the good riding weather goes south. In the meantime, the Kaptan and I are going to try to work this out for you guys. I knew that there had to be someone on this forum that could run with this. I will also post pic's of the shifter side this weekend for those of you that are interested.

  7. Oscar Maldonado

    Calendar Participant

    Joined:
    Jul 19, 2007
    Messages:
    5,860
    Likes Received:
    238
    Trophy Points:
    63
    Location:
    Louisiana
    My Bike(s):
    04' Pitbull
    First Name:
    Oscar
    That's awesome Bowhunter! Get me a price and I'll order a set from yall.

  8. BDWB

    BDWB Active Member

    Joined:
    Apr 12, 2007
    Messages:
    280
    Likes Received:
    5
    Trophy Points:
    18
    You can add me to the list of buyers - will you be making 1 length or 2, i.e. 4" and 6" options?

  9. KaptinAmerika

    KaptinAmerika Well-Known Member

    Joined:
    Mar 16, 2008
    Messages:
    4,739
    Likes Received:
    1,986
    Trophy Points:
    113
    Location:
    USA
    My Bike(s):
    2006 Big Dog K9
    First Name:
    Curtis
    Actually Bow has been very generous in turning the whole project over to me. What I would like from you folks is some info. I have the means to fabricate these but I need to put together some info on sizing, parts, e.t.c.
    So shoot me some PMs and lets get this project started.

  10. BBChopper

    BBChopper Supports 2 Disabled Vets
    Troop Supporter

    Joined:
    Nov 1, 2007
    Messages:
    17,484
    Likes Received:
    1,347
    Trophy Points:
    113
    Location:
    Fellsmere Fl,
    My Bike(s):
    2005 BDM Choppa "Wild Fire", 2011 Electra Glide Ultra Limited "Swamp Rat"
    First Name:
    Pablo
    Holy Shit your a Big Sum Bitch!!! :eek:
    Should have bought that "Shack" bike from West Coast Choppers!

    Good job on the custom parts!!:cheers::2thumbs:

    #30 BBChopper, May 8, 2010
    Last edited: May 8, 2010
  11. KaptinAmerika

    KaptinAmerika Well-Known Member

    Joined:
    Mar 16, 2008
    Messages:
    4,739
    Likes Received:
    1,986
    Trophy Points:
    113
    Location:
    USA
    My Bike(s):
    2006 Big Dog K9
    First Name:
    Curtis
    :roll::roll::roll::roll::lol::lol::roll::roll::roll:

    eehhh.......ooohh.....uhm

    What???

  12. Bowhunter

    Bowhunter Well-Known Member

    Joined:
    Mar 5, 2010
    Messages:
    2,270
    Likes Received:
    347
    Trophy Points:
    83
    Location:
    Oliver Springs, Tn.
    My Bike(s):
    2009 K9
    First Name:
    Steve
    O.K. guys, as promised, I am posting the shifter side of the extensions since we got in a time crunch the other night trying to get done before dark. I had Benny(Postman) come over for a follow up and some photos. I must admit that my perfectionist attitude has cost me some more time before I can give the master template over to Kaptin. You'll see what I mean from the photo.
    [​IMG]
    Here is the final product that I installed the other night, notice the angle of the shift petal that you must get your foot under to shift. Mighty tight ain't it!!
    [​IMG]
    Here is a close-up, notice that the shift petal is the same angle as it was in when it was 6" further back. But as you extend your leg, the toes start to point skyward.
    [​IMG]
    Here is the bracket I fabricated with the shifter removed, my mission now is to "clock" the shifter clockwise to rotate the shift pedal backwards so that the now skyward pointing foot can easily get under the pedal. Blue tape marks the new angle I determined to properly align the pedal.
    [​IMG]
    Here is the shifter after being "clocked" in a clockwise direction.
    [​IMG]
    And here is a overhead view showing the shift rod and the tight clearance. I trimmed 1/2" off the cone shaped spacer and the spacer bolt to get the shift rod to clear the frame.
    Now I have drawn a new template and gave it to my cousin to fab up a new shifter side bracket. When I get it back from him, I will redo my install on the shifter side and make a master template for Kaptin to run mass production with. I will post pictures of the final "IMPROVED" shifter side and you guys can order away. As a side note, I do plan to fab up a 4" extension plate template for myself and I will likewise turn it over to Kaptin to mass produce for you guys. Hope to get this finished up soon for you fellow "Long Legs". As I mentioned before, I made this 6" kit for the 6'4" (Postman), I feel that it is a little long for me since I am 6'2 1/2" and I will do the 4" for myself. Hope to get the Kaptin in business soon!

    PacoPetty likes this.
  13. Raywood

    Raywood The Pirate
    Staff Member Supporting Member

    Joined:
    Apr 5, 2007
    Messages:
    17,384
    Likes Received:
    720
    Trophy Points:
    113
    Location:
    Rainbow, CA
    My Bike(s):
    2014 KMW Regulator
    First Name:
    Ray
    Very nicely done Bow. :2thumbs:

  14. linx

    linx Active Member

    Joined:
    Nov 24, 2009
    Messages:
    926
    Likes Received:
    4
    Trophy Points:
    0
    Location:
    NashVegas, Tennessee
    My Bike(s):
    2006 Big Dog K9
    First Name:
    Rob
    Sweet!

  15. hollywoodjohnny

    Joined:
    Dec 16, 2009
    Messages:
    2,720
    Likes Received:
    13
    Trophy Points:
    0
    Location:
    Washington State
    My Bike(s):
    06 K-9
    Looks way koool ! nice job
    :cheers:

    #35 hollywoodjohnny, May 17, 2010
    Last edited: May 17, 2010
  16. avdhunter

    avdhunter Active Member

    Joined:
    Apr 12, 2009
    Messages:
    967
    Likes Received:
    12
    Trophy Points:
    18
    Location:
    Monroe, La
    My Bike(s):
    09 Ridgeback
    First Name:
    Louie
    :loony::loony::loony::loony::loony::loony::loony::loony:

  17. hollywoodjohnny

    Joined:
    Dec 16, 2009
    Messages:
    2,720
    Likes Received:
    13
    Trophy Points:
    0
    Location:
    Washington State
    My Bike(s):
    06 K-9
    The pics didn't load on my screen last night
    :cheers:

  18. avdhunter

    avdhunter Active Member

    Joined:
    Apr 12, 2009
    Messages:
    967
    Likes Received:
    12
    Trophy Points:
    18
    Location:
    Monroe, La
    My Bike(s):
    09 Ridgeback
    First Name:
    Louie
    Sorry couldn't pass that one up Hollywood........:whoop::cheers:

  19. hollywoodjohnny

    Joined:
    Dec 16, 2009
    Messages:
    2,720
    Likes Received:
    13
    Trophy Points:
    0
    Location:
    Washington State
    My Bike(s):
    06 K-9
    :roll: :roll: :roll: It's all good, when I looked this am there they were & I'm like WTF then saw your post and LMAO I would have done the same :lol:
    :cheers:

  20. bigtrav6442

    bigtrav6442 Member

    Joined:
    Jan 24, 2010
    Messages:
    137
    Likes Received:
    0
    Trophy Points:
    0
    Location:
    Jonesborough, TN
    My Bike(s):
    2008 K9
    First Name:
    Travis
    I can't wait for those 4 inch extentions to become reality!
